The DJI Agras T50 is a high-performance agricultural drone engineered for large-scale spraying and spreading applications. Designed to enhance operational efficiency, it integrates advanced technologies to deliver precise and reliable performance in diverse farming environments.

🌾 Key Specifications

Spray Tank Capacity: 40 liters (upgradeable to 50 liters with optional orchard kit)

Spreading Tank Capacity: 75 liters

Payload Capacity: Up to 40 kg for spraying; 50 kg for spreading

Spray Width: 4–11 meters

Spreading Width: Up to 8 meters

Max Takeoff Weight: 92 kg (spraying) / 103 kg (spreading)

Battery: DB1560 Intelligent Flight Battery (30 Ah)

Charging Time: Approximately 9 minutes for ultra-fast charging

Dimensions:

Unfolded: 2800×3085×820 mm

Folded: 1115×750×900 mm

Diagonal Wheelbase: 2200 mm

Weight:

Aircraft (excluding battery): 39.9 kg

Aircraft (including battery): 52 kg

Max Takeoff Weight: 92 kg (spraying) / 103 kg (spreading)

🧠 Advanced Features

Dual Atomizing Spraying System: Equipped with two LX8060SZ nozzles, it offers adjustable droplet sizes ranging from 50–500 μm, ensuring efficient pesticide and fertilizer application.

Dual Impeller Pumps: Delivers a maximum flow rate of 24 L/min (4 sprinklers), facilitating consistent and uniform spraying.

High-Torque Spreader: Achieves a spreading flow rate of up to 108 kg/min, enhancing efficiency in applying dry materials.

Phased Array Radar System: Provides 360° multidirectional obstacle sensing and terrain-following capabilities, with a maximum slope tolerance of 50°, ensuring stable flight in complex terrains.

Binocular Vision System: Offers precise altitude measurement and obstacle detection, supporting safe and accurate operations.

🚜 Applications

Spraying: Ideal for applying pesticides and fertilizers over large agricultural areas with precision.

Spreading: Efficiently distributes dry materials like seeds and granular fertilizers.

Mapping: Assists in creating detailed maps for crop monitoring and management.

Terrain Following: Adapts to varying ground elevations, maintaining consistent application rates.
